Specification:
Specification:
Conductor |
Insulation |
Braid shield |
Jacket |
AWG |
Material |
No./mm |
Diameter |
Material |
Diameter |
Material |
Construction |
Material |
Diameter |
46 |
SPTCA |
7/0.016 |
0.048 |
PFA |
0.12 |
SPTCA |
0.17 |
PFA |
0.22 |
44 |
SPTCA |
7/0.02 |
0.06 |
PFA |
0.13 |
SPTCA |
0.17 |
PFA |
0.23 |
44 |
SPTCA |
7/0.02 |
0.06 |
PFA |
0.15 |
SPTCA |
0.21 |
PFA |
0.23 |
44 |
SPTCA |
7/0.02 |
0.06 |
PFA |
0.15 |
TPTCA |
0.21 |
PFA |
0.26 |
42 |
SPTCA |
7/0.025 |
0.075 |
PFA |
0.17 |
SPTCA |
0.23 |
PFA |
0.28 |
42 |
SPTCA |
7/0.025 |
0.075 |
PFA |
0.17 |
TPTCA |
0.23 |
PFA |
0.28 |
42 |
SPTCA |
7/0.025 |
0.075 |
PFA |
0.18 |
TPTCA |
0.24 |
PFA |
0.31 |
40 |
SPTCA |
7/0.03 |
0.09 |
PFA |
0.24 |
TPTCA |
0.30 |
PFA |
0.35 |
40 |
TPTCA |
7/0.03 |
0.09 |
PFA |
0.24 |
TPTCA |
0.30 |
PFA |
0.35 |
36 |
SPTCA |
7/0.05 |
0.15 |
PFA |
0.27 |
TPTCA |
0.33 |
PFA |
0.38 |
36 |
TPTCA |
7/0.05 |
0.15 |
PFA |
0.27 |
TPTCA |
0.33 |
PFA |
0.38 |
SPTCA: Silver plated Tin-copper alloy
TPTCA: Tin plated Tin-copper alloy
